Case 08 2026: A Hella Lamella: A Three-Flap, Full-Thickness Lower Eyelid Reconstruction
Sondre F. Koren (MD), Jette B. Løvenwald (MD). Roskilde, SUH, Denmark
Abstract
Keywords: Eyelid reconstruction, Hughes flap, tarsoconjunctival flap, periosteal flap, periorbital, scc, cheek rotational flap, Z-plasty Authors: Sondre F. Koren (MD), Jette B. Løvenwald (MD). Roskilde, SUH, Denmark. Abstract An 83-year-old male with atrial fibrillation, stage 4 chronic kidney disease, chronic heart failure, monoclonal gammopathy of undetermined significance (MGUS), and glaucoma presented with a 35 × 35 × 15 mm ulcerated squamous cell carcinoma (SCC) of the lateral right lower eyelid. Frozen section-guided full-thickness excision was performed under general anaesthesia. Reconstruction was accomplished in two stages. In the first stage, a combined pedicled tarsoconjunctival flap and a laterally-based periosteal flap (posterior lamella), and a cheek rotation flap (anterior lamella) were used. Frost sutures provided corneal protection during the 4-week inter-stage interval. In the second stage, flap division was performed under general anaesthesia, incorporating Müller's muscle release to prevent upper eyelid retraction. A small dehiscence at the medial flap junction had resulted in a minor notch, which was ultimately resolved with Z-plasty and release of the underlying inferior scar contracture on the cheek. Final histopathology confirmed highly differentiated SCC with clear margins. The multidisciplinary tumour board found no indication for adjuvant therapy. At 23 days following flap division, the patient was satisfied with the functional and aesthetic result. Patient medical history The patient underwent surgery after a 7-week history of a growing tumour of the cheek and lateral lower eyelid. The punch biopsy reported keratoacanthoma/highly differentiated SCC. The tumour had been observed to assess for spontaneous regression, but continued to grow. He had stage 4 chronic kidney disease, treated with Darbepoetin alfa (Aranesp), and glaucoma treated with Latanoprost eye drops, which he had not been taking for several months, with no documented decline
BeforeAfterThe patient underwent surgery after a 7-week history of a growing tumour of the cheek and lateral lower eyelid. The punch biopsy reported keratoacanthoma/highly differentiated SCC. The tumour had been observed to assess for spontaneous regression, but continued to grow. He had stage 4 chronic kidney disease, treated with Darbepoetin alfa (Aranesp), and glaucoma treated with Latanoprost eye drops, which he had not been taking for several months, with no documented decline in vision. His atrial fibrillation was managed with warfarin (Marevan) and beta-blockers. He was a non-smoker, ambulatory without assistive devices, living independently, and managing activities of daily living without assistance.
The tumour was marked with a 5 mm margin, and a protective shell was placed on the cornea. The excision was taken down to the preseptal fat. Frozen sections were sent, and all margins returned negative. The upper lateral canthal ligament was left intact; the lower was excised.
A stay suture was placed through the grey line of the upper eyelid, and a Desmarres retractor was placed, facilitating retraction of the lid and keeping it everted during the procedure. A tarsoconjunctival flap from the upper eyelid was marked, preserving 4 mm of tarsus inferior to the flap to maintain the upper eyelid framework. As the tarsal plate tapers towards the lateral edges, the flap was harvested more medially than the defect to achieve the required length, while preserving the aforementioned 4 mm of tarsus. The levator tandon was divided from the tarsal plate, along with a portion of Müller’s muscle, leaving a pedicle of the remaining muscle and the conjunctiva. The flap was advanced inferiorly to the defect and sutured tension-free with 5-0 and 6-0 Vicryl.
2
A periosteal flap was designed with a 30-degree superior angulation relative to the intercanthal horizontal line, to maintain a superior vector and protect against ectropion. The flap was raised with the distal portion incorporating temporal fascia, harvested slightly longer than required and with a width of 7–8 mm. After turning it over as a hinge flap, the length was trimmed to achieve appropriate tension for suspension of the lower posterior lamella, and the flap was sutured to the tarsoconjunctival flap with 5-0 PDS mattress sutures. The upper lateral canthal ligament was then sutured to the periosteal flap to reconstruct the common canthal ligament and recreate the sharp angle between the upper and lower canthal ligaments, using 5-0 Prolene.
3
The anterior lamella was reconstructed with a classic cheek rotation flap raised on the SMAS. A pexy of the flap to the periosteum of the lateral orbital rim was performed with 3-0 PDS. The flap was then closed with 4-0, 5-0, and 6-0 Vicryl and 5-0 and 6-0 Prolene over a glove drain, which exited anterior to the ear.
4
After the photograph was taken, Frost sutures were passed through the grey line and taped to the forehead to protect the cornea and relieve tension on the reconstruction.
5
6
Following the first stage, the importance of not discharging the patient to his home alone was emphasised, as he was now monocular due to the bridging tarsoconjunctival flap, had pre-existing glaucoma, and was on anticoagulation therapy — all of which posed a significant risk of falls and trauma. He was therefore kept admitted until a place became available at a rehabilitation facility. Sutures were removed at 7 days, on the day of discharge, and prophylactic antibiotics were continued until the same day. A standard postoperative regimen was ordered for the first few days, including head of bed elevation and a soft diet.
Following the second stage, the patient was discharged on the same day and sutures were removed at nine days. Chloramphenicol ointment was applied as topical prophylaxis during this period.
A head and neck ultrasound performed six weeks postoperatively demonstrated no evidence of lymph node metastasis.
How to cite this article
Sondre F. Koren (MD), Jette B. Løvenwald (MD). Roskilde, SUH, Denmark. Case 08 2026: A Hella Lamella: A Three-Flap, Full-Thickness Lower Eyelid Reconstruction. Journal of Plastic, Breast & Reconstructive Surgery. 2026.
Open access. © 2026 The Author(s). Published by the Journal of Plastic, Breast & Reconstructive Surgery. Copyright to this case is shared between the author(s) and the journal; authors may reuse their own case for education, presentations and social media.
